Product Details:
Payment & Shipping Terms:
|
| Capacity: | 1800 GPM | Hydrocyclone Specs: | 12" |
|---|---|---|---|
| Hydrocyclone Qty: | 3pcs | Working Pressure: | 0.25-0.4Mpa |
| Inlet Diameter: | 8" | Outlet Diameter: | 10" |
| Separation Point: | 60-200 μm | ||
| Highlight: | Drilling Mud Desanding Equipment,200 ΜM Drilling Mud Desander,300m3/H Drilling Mud Desander |
||
1800 GPM Drilling Mud Desander Without Bottom Shaker
Introduction
Drilling mud desander is the second stage cleaning of the whole solids control system. It is located on the mud tank and separates drilling cuttings of 47-76 microns and above by centrifugal force. Untreated slurry enters the desander cone from the horizontal inlet under pressure. The pressure and weight cause the solid particles to move near the cone wall and fall down. The fluid particles are pressed against the top and overflow through the pipe. There can be a vibrator to collect solids from the desander nozzle or drip directly onto the hopper.
Our mud desander is mainly used to remove finer solid particles in drilling fluid. The desalting capacity of this equipment is 30%-50% higher than that of the previous desander, which provides a reliable guarantee for increasing the drilling speed and reducing the drilling cost, and can also play the role of sand and mud removal in deep wells.
Main Benefits of TR Drilling Mud Desander
Main Parameters of TR Drilling Mud Desander
| Model | TRCS200-1S/2S | TRCS250-1S/2S | TRCS250-3S | TRCS300-1S/2S |
| Capacity | 60m3/120m3/h | 100m3/200m3/h | 300m3/h | 120m3/240m3/h |
| Cyclone Specs | 8” | 10” | 10” | 12” |
| Cyclone Qty | 1nos/2nos | 1nos/2nos | 3nos | 1nos/2nos |
| Working Pressure | 0.25-0.4Mpa | |||
| Inlet Size | DN125mm | DN150mm | DN150mm | DN150mm |
| Outlet Size | DN150mm | DN200mm | DN200mm | DN200mm |
| Separation Point | 45μm -75μm | |||
| Bottom Shaker | TRTS60 | TRTS60 | TRZS752 | TRZS752 |
| Dimension | 1510*1160*2000mm | 1510*1360*2250mm | 1835*1230*1810mm | 1835*1230*1810mm |
| Weight | 570kg/620kg | 670kg/760kg | 1300kg | 1380kg |
| Remark | All desander could be customized without bottom shaker. | |||
Application
Our Mud Desander is widely used in solid liquid separation, city bored piling, Drilling Waste Management, trenchless HDD, oil & gas drilling, tunneling construction, Oil Mud Seperation, Coal Bed Gas Solids Control System, mining, Oil Sludge Dewatering Systems, environment protection, Water Drilling etc. Our mud desander has good price and short delivery. It conforms to both API and ISO standard. We are sincerely waiting for your consulting!
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
