| Capacity: | 130m3/h | Motor Power: | 1.94+1.0kw |
|---|---|---|---|
| Screen Area: | 2.6m2 | Double Amplitude: | 7mm |
| Ex Standard: | ExdllBt4 | Vibration Motion: | Balanced Elliptical Motion |
| Screen Specs.: | (700*1250mm)*3pcs | Vibration Strength: | ≤7.1G(Adjustabe) |
| Adjustment Angle: | -1°-+5° | Weight: | 1630kg |
| Highlight: | mud shaker,drilling fluid equipment |
||
Vibration Mode Oilfield Shale Shaker Solids Control Elliptical Balanced
Product Introduction
Mud shale shaker is first phase solid control equipment in drilling fluids processing system. It's also known as the key solids control equipment in drilling mud system. Shale shaker decides performance of the whole solids control system. We can design double shale shaker and triplicate shakers on single skid according to clients' special requirements. TR also supply relevant connecting manifold, according to current industry situation. We provide both third generation linear motion shale shaker and fourth generation balanced elliptical shale shaker.
TR Solids Control can manufacture balanced elliptical shale shaker, high quality liner shale shaker, drying shale shaker. We can meet customers' variable requirements. Clients feedback proved the advantages of our shale shaker in international market. Welcome to contact with us for more details.
Main features of our mud shale shaker
Technical Specifications of Our Shale Shaker
| (Model) | TRPS703 | TRPS585-4 | TRZS703 | TRZS585 |
| Vibration Motion | Balanced Elliptical Motion | Linear Motion | ||
| Treatment Capacity | 130m³/h | 140m³/h | 120m³/h | 130m³/h |
| Motor Power | 1.94+1.0kw | 1.94+1.0kw | 1.5KW×2 | 1.72KW×2 |
| Screen Specs. | (700×1250mm)×3 | (585×1165mm)×4 | (700×1250mm)×3 | (585×1165mm)×4 |
| Screen Area | 2.6m² | 2.7m² | 2.6m² | 2.7m² |
| Vibration Strength | ≤7.1G | ≤7.1G | ≤7.1G | ≤7.1G |
| Double Amplitude | 7mm | 7mm | 6mm | 6mm |
| Deck Adjustment | -1°～+5° | -1°～+5° | -1°～+5° | -1°～+5° |
| Ex Standard | ExdIIBt4 / IECEX / A-TEX | |||
| Weight | 1630kg | 1618kg | 1620kg | 1600kg |
| Dimension | 2770×1785×1690mm | 2966×1600×1280mm | 2770×1785×1690mm | 2966×1600×1280mm |
| Remark | Above data are tested from the drilling mud with viscosity 45s,and specific gravity 1.2g/cm3. | |||
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
