Product Details:
Payment & Shipping Terms:
|
| Capacity: | 130m3/h | Motor Power: | 1.72kw*2 |
|---|---|---|---|
| Screen Area: | 2.7m2 | Double Amplitude: | 6mm |
| Ex Standard: | ExdllBt4 | Vibration Motion: | Linear Motion |
| Screen Specs.: | (585*1165mm)*3pcs | Vibration Strength: | ≤7.1G(Adjustabe) |
| Adjustment Angle: | -1°-+5° | Weight: | 1600kg |
| Highlight: | mud shaker,drilling fluid equipment |
||
Drilling Mud Fluids Solid Control Shale Shaker / Linear Motion Drilling Shale Shaker
Introduction
Drilling fluid shale shaker is the primary solids control equipment in the drilling fluid solids control system. The shale shaker sreens the drilling fluid with great amount cuttings, separates the large-size solid particles, and sends the drilling fluid to the next seperating equipments. Our shale shaker has the advantages of simple structure,reliable performance,large disposal capacity,long service life,and simple maintenance.
TR shale shaker absorbed advanced tech at home and abroad, complete series shale shaker can meet customers’variable demand. Clients feedback proved the advantages of this kind of shale shaker: high G-force, wide screen area, compressed structure, cost-effective, etc. Nowadays we mainly provide both third generation linear motion shale shaker and fourth generation balanced elliptical shale shaker.
Key Charateristics of Our Mud Shale Shaker:
Parameters of TR Drilling Shale Shaker
| Model | TRPS703 | TRPS585-4 | TRZS703 | TRZS585 |
| Vibration Motion | Balanced Elliptical Motion | Linear Motion | ||
| Treatment Capacity | 130m³/h | 140m³/h | 120m³/h | 130m³/h |
| Motor Power | 1.94+1.0kw | 1.94+1.0kw | 1.5KW×2 | 1.72KW×2 |
| Screen Specs. | (700×1250mm)×3 | (585×1165mm)×4 | (700×1250mm)×3 | (585×1165mm)×4 |
| Screen Area | 2.6m² | 2.7m² | 2.6m² | 2.7m² |
| Vibration Strength | ≤7.1G | ≤7.1G | ≤7.1G | ≤7.1G |
| Double Amplitude | 7mm | 7mm | 6mm | 6mm |
| Deck Adjustment | -1°～+5° | -1°～+5° | -1°～+5° | -1°～+5° |
| Ex Standard | ExdIIBt4 / IECEX / A-TEX | |||
| Weight | 1630kg | 1618kg | 1620kg | 1600kg |
| Dimension | 2770×1785×1690mm | 2966×1600×1280mm | 2770×1785×1690mm | 2966×1600×1280mm |
| Remark | Above data are tested from the drilling mud with viscosity 45s,and specific gravity 1.2g/cm3. | |||
Application
Our drilling shale shaker is currently used in trenchless HDD, Drilling Waste Management, oil & gas drilling, city bored piling, tunneling construction, micro-tunneling, environment protection, mining, Oil Sludge Dewatering Systems, Oil Mud Seperation, Coal Bed Gas Solids Control System, Water Drilling etc.
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
