Product Details:
Payment & Shipping Terms:
|
| Model: | 100YZ120-60 | Flow: | 120m3/h |
|---|---|---|---|
| Lift: | 40m | Speed: | 1480r/min |
| Motor: | 45kw | Appllication: | Oil & Gas Drilling, Trechless HDD & Tunnel, Drilling Waste Management |
| Highlight: | Semi Open Impeller Submersible Centrifugal Pump,1480r/Min Submersible Mud Pump,Oilfield Solid Control Submersible Mud Pump |
||
Stable Operation Submersible Slurry Pump for Oilfield Solid Control System
Product Introduction
Our YZ series submersible slurry pump mainly supply mud for shale shaker and decanter centrifuge from the mud pit. It can transport large particles of solid particles. Pump inserted in the liquid length usually is between 800mm to 1900mm, and it can be equipped with suction pipe if necessary. The drive is mounted on the motor base by a vertical motor and connected to the pump with a coupling.
Single screw pump is used in all fields widely to feel kinds of medium, running at a constant pressure continuously, without pulse and damage when feeding medium, and change the gauging aim through adjusting rotation speed.
Submersible slurry pump normally is used for feeding shale shaker for CBM, HDD or other drilling industry. The pump rotates clockwise from the direction of the motor. It is vertical single stage and single suction system and made of abrasion-resistant alloy. The standard length of pump 1.3m, but TR submersible slurry pump can be customized.
Main Advantages of Our Submersible Slurry Pump
Technical Data of YZ Series Submersible Slurry Pump
| Model | Flow | Lift | Speed | Motor |
| 50YZ25-12 | 25m3/h | 12m | 1430r/min | 3kw |
| 50YZ20-18 | 20m3/h | 18m | 1430r/min | 4kw |
| 80YZ50-20B | 40m3/h | 16m | 1440r/min | 5.5kw |
| 80YZ50-20 | 60m3/h | 17.5m | 1440r/min | 7.5kw |
| 80YZ80-20 | 90m3/h | 22m | 1460r/min | 11kw |
| 100YZ100-30A | 75m3/h | 30m | 1470r/min | 18.5kw |
| 100YZ100-30 | 60m3/h | 36m | 1470r/min | 22kw |
| 100YZ160-38B | 82m3/h | 33m | 1480r/min | 30kw |
| 100YZ120-60 | 120m3/h | 40m | 1480r/min | 45kw |
| 150YZ250-40A | 135m3/h | 35m | 1480r/min | 55kw |
| 150YZ250-40B | 120m3/h | 28m | 1480r/min | 37kw |
Our submersible slurry pump has exported to many countries like Vietnam, Egypt, Germany, UAE, US etc. Welcome your inquiry!
In addition, we supply other solid control equipment like shale shaker, mud cleaner, decanter centrifuge, jet mud mixer, desilter, vertical cutting dryer and so on.
Our submersible slurry pump has good price and short delivery. Welcome your inquiry and consulting!
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
