Product Details:
Payment & Shipping Terms:
|
| Advantage: | Environmental Friendly | Color: | White |
|---|---|---|---|
| Material: | Carbon Steel | ||
| Highlight: | Recycling Drilling Fluids Clear Water Tank,Solids Control Clear Water Tank,Skid Mounted Mud Waste Management Systems |
||
Environmental Friendly WBM Drilling Waste Management
System Introduction
Mud not landing system is the common name of drilling waste treatment, also known as drilling fluid does not land, refers to the use of mud not landing equipment to screen the waste in drilling fluid. The equipment for mud not falling to the ground generally includes drying shaker, drilling cuttings dryer and high-speed mud centrifuge.
Drilling waste management systems are packages of different function for drilling waste management. Usually include high G drying shaker, auger feeder or screw conveyor, skid mounted cuttings dryer, and decanter centrifuge with telescopic skid, drilling cuttings tank or mud skips.
We are not a one size fits all treatment provider. To deliver totally customized waste management solutions, we leverage a broad portfolio of modular to deploy unique configurations tailored to your operating needs. From shakers to cuttings dryer, conveyance systems to thermal processing units, we have the right products to tackle any challenge, and the expertly trained personnel to implement the ideal solution.
Characterstics of Drilling Waste Management Scheme
Main Configuration of TR Drilling Waste Management
| S/N | S/N | Description |
| 1 | Vertical Cuttings Dryer | TRCD930 with option for VFD or fixed speed |
| 2 | Decanter Centrifuge | TRGLW355Centrifuge 14inch bowl,Optional model as below: TRGLW355 Centrifuge with VFD drive. TRGLW355 standard with fixed speed |
| 3 | Screw Pump | Two sets TRG30A-075 Screw Pump with capacity:30m³/h for each pump. One for taking fluids from catching tank to feed the decanter centrifuge,the other for flushing the Vertical dryer. |
| 4 | Skid with catching tank | Fast move skid for mounting all the equipment One Catching tank with capacity:4m³ for catching fluid from vertical cuttings dryer. |
| 5 | Telescopic Skid | Two telescopic skid with walkways and handrails for safe operation. One for mounting the decanter centrifuge to a higher position in order to allow the centrifuge discharged fluids feed to active mud system by gravity. The other telescopic skid for mounting and adjusting the height of the vertical cutting dryer to allow the discharge of drying cuttings |
| 6 | Electric Cradle | 0.5 Tons electric cradle for lifting the components of vertical dryer |
| 7 | Electric Control System | Two lighting system,electrical control boxes and cables and plugs for operation the complete system. |
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
